Crawler-Type Mobile Cone Plant (Full Hydraulic)

Crawler-Type Mobile Cone Plant (Full Hydraulic)

Model:

Production Capacity:

Cone type mobile crushing station host is used at present, the most widely used in the international market, one of the best-selling products, multi-cylinder hydraulic cone crusher, the aircraft cone crushing technology, hydraulic technology, compute

Description

2

Introduction
Cone type mobile crushing station host is used at present, the most widely used in the international market, one of the best-selling products, multi-cylinder hydraulic cone crusher, the aircraft cone crushing technology, hydraulic technology, computer technology and manufacturing technology and so on the latest research results at an organic whole, can choose different according to the needs of the customer for material processing chamber type.

Advantages
1.Curve crushing chamber: according to the crushing principle of material layer and wear characteristic of cavity wall, the cavity type design is curve, which can ensure the target of high output, high quality and low wear cost
2.Main crusher adopts automatic control system, with automatic crushing process control, one-button automatic start and advanced fault diagnosis function, can achieve crushing operation overload protection or iron protection and other functions;
3.Adjustable eccentricity: the main crusher eccentric bushing, eccentric bushing combination, by rotating eccentric bushing can easily achieve multiple eccentricity setting, to adapt to the requirements of different ores and mines
4.Advanced hydraulic lubrication system: main crusher lubrication system, hydraulic system modular design, independent operation, can achieve oil temperature, flow, pressure, power, abnormal power protection
5.According to customer needs, optional iron remover or return system, or plate feeding system.

Technical Parameters

SR-HPY300 Crawler-Type Mobile Cone Plant (Full Hydraulic )
Vibrating Feeder Diesel Engine
Capacity(m³) 5.4 Brand Cummins
Materials Q345 steel & wear-resistant steel Power(Kw) 410
Height(mm) 2800 Control System The electro-hydraulic integrated, wireless remote control
Main Conveyor Transportation Size
Main Conveyor Size(mm) 10000*1000 Total Length(mm) 14900
Output Height(mm) 3200 Total Height (mm) 3600
Max. Height(mm) 2800 Total Width(mm) 3000
Cone Crusher Walk unit
Feeder Size(mm) 35-185 Size(mm) 4300*500
Discharging Mouth(mm) 8-58 Walk Speed(m/min) 12.5-20
Working Capacity 250-350t/h Total Weight(t) 65
